Product Features
-Micro-computer control, imported Motorola sensor, high accuration and precision.
-During the sterilizing procedure, the range of temperature is ±0.5.
-Automatic cleaning program in the steamer, avoid the occlution.
-Display the sterilizing procedure date and curve.
-Water quality monitoring,indicate the water tank condition, automatic notice when used water tank is full.
-Safety valve, double lock, mechanical lock, air lock, multi pressure safe protection device.
-Printer is optional, record the sterilizing procedure with USB.
-Applied with stomatology, orthopedics, ophthalmology, beauty industries and other area.
Specification
|
Equipment |
Steam sterilizer |
|
Classification |
Class B |
|
Model |
ST-16LED,ST-18LED,ST-23LED |
|
Manufacturer |
Foshan MIC Medical Technology Co.,Ltd |
|
Power supply |
220V±10% |
|
Frequency |
50Hz±1 Hz |
|
Mains fuses |
F 15A 250V |
|
External dimensions (LxDxH) |
610 x 460 x 420 mm (rear connections excluded) |
|
Nominal power |
W (13 A) |
|
Insulation class |
Class II |
|
Utilization |
Internal use |
|
Acoustic noise level |
50 db(A) max |
|
Environmental operating conditions |
Temperature: 5℃~40°C Relative Humidity: max 80%, non condensing Height: max 3000 m (a.s.l.) |
|
Net weight |
16L approx. 41 KG 18L approx. 46 KG 23L approx. 54 KG |
|
Sterilization chamber dimensions (Lmax x Hmax) |
16L: 230 x 360 mm 18L: 250 x 380 mm 23L: 250 x 450 mm |
|
Capacity of the distilled water reservoir
|
approx. 5L ( water at level MAX ) |
|
Sterilization programmes |
Available: 6 Preset: 4 ( directly selected by the operator ) |
|
Test programmes |
Helix / BD Test Vacuum Test |
|
Pre-heating time (from cold) |
approx. 20 mins |
Steam sterilizer detail pictures
Steam sterilizer production line
Fair picture
Delivery Way
Service Details
-Lead time: Within 3~6 working days after payment is confirmed;
-QC: Each product will be 100% checked before shipment;
-OEM & ODM service optional depends on the specific terms and condition;
-2 Years warranty with professional engineer support;
-During 1 year, If machine have problem we supply spare parts for free;
